28MG SERIES

The Gowanda 28MG series of non-magnetic RF thru-hole inductors offers an inductance range from 1.2 µH to 18 µH, with DC resistance (DCR) values from 0.079 to 4.15 ohms and current ratings from 315 to 2400 mA DC, making them ideal for applications in medical imaging, telecommunications, and other fields where magnetic materials must be avoided. These inductors feature a relative permeability of ≤ 1.00003, operate over a temperature range of -55°C to +125°C, and are epoxy encapsulated for environmental protection and durability.

PARAMETRIC SEARCH

Name	Mounting	Inductance (µH)	DCR (Ω)	Current Rating (A DC)	SRF (MHz)	Tolerance	Termination	hf:tax:pa_mounting-type	hf:tax:pa_inductance-µh	hf:tax:pa_dcr-ω	hf:tax:pa_current-rating-a-dc	hf:tax:pa_srf-mhz	hf:tax:pa_tolerance	hf:tax:pa_termination-type	hf:tax:pa_series
28MG182MLF	THT	18	4.15	0.315	45	±20%	RoHS	tht	18	4-15	0-315	45	%c2%b120	rohs	28mg
28MG182M	THT	18	4.15	0.315	45	±20%	Pb	tht	18	4-15	0-315	45	%c2%b120	pb	28mg
28MG182KLF	THT	18	4.15	0.315	45	±10%	RoHS	tht	18	4-15	0-315	45	%c2%b110	rohs	28mg
28MG182K	THT	18	4.15	0.315	45	±10%	Pb	tht	18	4-15	0-315	45	%c2%b110	pb	28mg
28MG152MLF	THT	15	3.25	0.355	50	±20%	RoHS	tht	15	3-25	0-355	50	%c2%b120	rohs	28mg
28MG152M	THT	15	3.25	0.355	50	±20%	Pb	tht	15	3-25	0-355	50	%c2%b120	pb	28mg
28MG152K	THT	15	3.25	0.355	50	±10%	Pb	tht	15	3-25	0-355	50	%c2%b110	pb	28mg
28MG152KLF	THT	15	3.25	0.355	50	±10%	RoHS	tht	15	3-25	0-355	50	%c2%b110	rohs	28mg
28MG122MLF	THT	12	2.65	0.395	53	±20%	RoHS	tht	12	2-65	0-395	53	%c2%b120	rohs	28mg
28MG122M	THT	12	2.65	0.395	53	±20%	Pb	tht	12	2-65	0-395	53	%c2%b120	pb	28mg
28MG122KLF	THT	12	2.65	0.395	53	±10%	RoHS	tht	12	2-65	0-395	53	%c2%b110	rohs	28mg
28MG122K	THT	12	2.65	0.395	53	±10%	Pb	tht	12	2-65	0-395	53	%c2%b110	pb	28mg
28MG102MLF	THT	10	1.9	0.46	60	±20%	RoHS	tht	10	1-9	0-46	60	%c2%b120	rohs	28mg
28MG102M	THT	10	1.9	0.46	60	±20%	Pb	tht	10	1-9	0-46	60	%c2%b120	pb	28mg
28MG102KLF	THT	10	1.9	0.46	60	±10%	RoHS	tht	10	1-9	0-46	60	%c2%b110	rohs	28mg
28MG102K	THT	10	1.9	0.46	60	±10%	Pb	tht	10	1-9	0-46	60	%c2%b110	pb	28mg
28MG821MLF	THT	8.2	1.4	0.55	68	±20%	RoHS	tht	8-2	1-4	0-55	68	%c2%b120	rohs	28mg
28MG821M	THT	8.2	1.4	0.55	68	±20%	Pb	tht	8-2	1-4	0-55	68	%c2%b120	pb	28mg
28MG821KLF	THT	8.2	1.4	0.55	68	±10%	RoHS	tht	8-2	1-4	0-55	68	%c2%b110	rohs	28mg
28MG821K	THT	8.2	1.4	0.55	68	±10%	Pb	tht	8-2	1-4	0-55	68	%c2%b110	pb	28mg
28MG681MLF	THT	6.8	1.05	0.635	75	±20%	RoHS	tht	6-8	1-05	0-635	75	%c2%b120	rohs	28mg
28MG681M	THT	6.8	1.05	0.635	75	±20%	Pb	tht	6-8	1-05	0-635	75	%c2%b120	pb	28mg
28MG681KLF	THT	6.8	1.05	0.635	75	±10%	RoHS	tht	6-8	1-05	0-635	75	%c2%b110	rohs	28mg
28MG681K	THT	6.8	1.05	0.635	75	±10%	Pb	tht	6-8	1-05	0-635	75	%c2%b110	pb	28mg
28MG561MLF	THT	5.6	0.745	0.745	80	±20%	RoHS	tht	5-6	0-745	0-745	80	%c2%b120	rohs	28mg
28MG561M	THT	5.6	0.745	0.745	80	±20%	Pb	tht	5-6	0-745	0-745	80	%c2%b120	pb	28mg
28MG561K	THT	5.6	0.745	0.745	80	±10%	Pb	tht	5-6	0-745	0-745	80	%c2%b110	pb	28mg
28MG561KLF	THT	5.6	0.745	0.745	80	±10%	RoHS	tht	5-6	0-745	0-745	80	%c2%b110	rohs	28mg
28MG471MLF	THT	4.7	0.56	0.86	90	±20%	RoHS	tht	4-7	0-56	0-86	90	%c2%b120	rohs	28mg
28MG471M	THT	4.7	0.56	0.86	90	±20%	Pb	tht	4-7	0-56	0-86	90	%c2%b120	pb	28mg
28MG471KLF	THT	4.7	0.56	0.86	90	±10%	RoHS	tht	4-7	0-56	0-86	90	%c2%b110	rohs	28mg
28MG471K	THT	4.7	0.56	0.86	90	±10%	Pb	tht	4-7	0-56	0-86	90	%c2%b110	pb	28mg
28MG391M	THT	3.9	0.45	0.955	95	±20%	Pb	tht	3-9	0-45	0-955	95	%c2%b120	pb	28mg
28MG391MLF	THT	3.9	0.45	0.955	95	±20%	RoHS	tht	3-9	0-45	0-955	95	%c2%b120	rohs	28mg
28MG391KLF	THT	3.9	0.45	0.955	95	±10%	RoHS	tht	3-9	0-45	0-955	95	%c2%b110	rohs	28mg
28MG391K	THT	3.9	0.45	0.955	95	±10%	Pb	tht	3-9	0-45	0-955	95	%c2%b110	pb	28mg
28MG331MLF	THT	3.3	0.305	1.15	100	±20%	RoHS	tht	3-3	0-305	1-15	100	%c2%b120	rohs	28mg
28MG331M	THT	3.3	0.305	1.15	100	±20%	Pb	tht	3-3	0-305	1-15	100	%c2%b120	pb	28mg
28MG331KLF	THT	3.3	0.305	1.15	100	±10%	RoHS	tht	3-3	0-305	1-15	100	%c2%b110	rohs	28mg
28MG331K	THT	3.3	0.305	1.15	100	±10%	Pb	tht	3-3	0-305	1-15	100	%c2%b110	pb	28mg
28MG271MLF	THT	2.7	0.22	1.35	115	±20%	RoHS	tht	2-7	0-22	1-35	115	%c2%b120	rohs	28mg
28MG271M	THT	2.7	0.22	1.35	115	±20%	Pb	tht	2-7	0-22	1-35	115	%c2%b120	pb	28mg
28MG271KLF	THT	2.7	0.22	1.35	115	±10%	RoHS	tht	2-7	0-22	1-35	115	%c2%b110	rohs	28mg
28MG271K	THT	2.7	0.22	1.35	115	±10%	Pb	tht	2-7	0-22	1-35	115	%c2%b110	pb	28mg
28MG221MLF	THT	2.2	0.16	1.6	125	±20%	RoHS	tht	2-2	0-16	1-6	125	%c2%b120	rohs	28mg
28MG221M	THT	2.2	0.16	1.6	125	±20%	Pb	tht	2-2	0-16	1-6	125	%c2%b120	pb	28mg
28MG221KLF	THT	2.2	0.16	1.6	125	±10%	RoHS	tht	2-2	0-16	1-6	125	%c2%b110	rohs	28mg
28MG221K	THT	2.2	0.16	1.6	125	±10%	Pb	tht	2-2	0-16	1-6	125	%c2%b110	pb	28mg
28MG181MLF	THT	1.8	0.135	1.75	140	±20%	RoHS	tht	1-8	0-135	1-75	140	%c2%b120	rohs	28mg
28MG181M	THT	1.8	0.135	1.75	140	±20%	Pb	tht	1-8	0-135	1-75	140	%c2%b120	pb	28mg
28MG181KLF	THT	1.8	0.135	1.75	140	±10%	RoHS	tht	1-8	0-135	1-75	140	%c2%b110	rohs	28mg
28MG181K	THT	1.8	0.135	1.75	140	±10%	Pb	tht	1-8	0-135	1-75	140	%c2%b110	pb	28mg
28MG151MLF	THT	1.5	0.09	2.15	160	±20%	RoHS	tht	1-5	0-09	2-15	160	%c2%b120	rohs	28mg
28MG151M	THT	1.5	0.09	2.15	160	±20%	Pb	tht	1-5	0-09	2-15	160	%c2%b120	pb	28mg
28MG151K	THT	1.5	0.09	2.15	160	±10%	Pb	tht	1-5	0-09	2-15	160	%c2%b110	pb	28mg
28MG151KLF	THT	1.5	0.09	2.15	160	±10%	RoHS	tht	1-5	0-09	2-15	160	%c2%b110	rohs	28mg
28MG121MLF	THT	1.2	0.079	2.4	170	±20%	RoHS	tht	1-2	0-079	2-4	170	%c2%b120	rohs	28mg
28MG121M	THT	1.2	0.079	2.4	170	±20%	Pb	tht	1-2	0-079	2-4	170	%c2%b120	pb	28mg
28MG121KLF	THT	1.2	0.079	2.4	170	±10%	RoHS	tht	1-2	0-079	2-4	170	%c2%b110	rohs	28mg
28MG121K	THT	1.2	0.079	2.4	170	±10%	Pb	tht	1-2	0-079	2-4	170	%c2%b110	pb	28mg

Notes

Current Rating is based on a 35°C temperature rise at an ambient temperature of 90°C
Relative Permeability: ≤1.00003
MSL Rating: 1
Epoxy-encapsulated for environmental protection and superior strength to withstand all types of reflow soldering
Custom designs are available to meet your specific requirements;
please contact factory

Termination:

Sn63Pb37 (Tin/Lead) for Pb components

Sn/Cu (Tin/Copper) for RoHS components

Environmental

Environmental:

RoHS Compliant

Operating Temperature Range:

-55°C to +125°C

Storage Temperature:

-55°C to +125°C
