Gowanda’s 050AT2503H is a high-quality horizontal open construction toroidal inductor, designed for reliable performance in demanding applications. With a compact size of 15.88 × 15.88 × 7.62 mm and a weight of 5 grams, it is part of the AT series and features through-hole technology (THT) for easy mounting. This component is suitable for COTS+ application grades, offering an inductance of 250 µH, a direct current resistance (DCR) of 0.16 Ω, and a self-resonant frequency (SRF) of 1.5 MHz. It supports a current rating of 1.84 A DC, with incremental current limits of 900 mA DC for a 10% change and 1400 mA DC for a 20% change. The inductor has a tolerance of ±10% and uses Pb termination with a Sn63Pb37 finish. It operates efficiently across a wide temperature range from -55°C to +130°C, has a moisture sensitivity level (MSL) of 1, and is available in bulk packaging.
| Weight | 5 g |
|---|---|
| Dimensions | 15.88 × 15.88 × 7.62 mm |
| Series | AT |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 250 |
| DCR (Ω) | 0.16 |
| SRF (MHz) | 1.5 |
| Current Rating (A DC) | 1.84 |
| INC I L (Δ10% mA DC) | 900 |
| INC I L (Δ20% mA DC) | 1400 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Operating Temperature | -55°C to +130°C |
| MSL | 1 |
| Packaging | Bulk |
Horizontal Open Construction Toroidal inductor
