Gowanda’s 050AT3901HM is a high-quality horizontal mount standoff toroidal choke, part of the ATHM series, designed for surface mount technology (SMT) applications. It features an inductance of 3.9 µH with a direct current resistance (DCR) of 0.006 Ω and a self-resonant frequency (SRF) of 35 MHz. The component supports a current rating of 9.5 A DC, with incremental current levels of 8500 mA DC for a 10% inductance change and 12000 mA DC for a 20% change. It has a tolerance of ±15% and utilizes a Pb termination type with a Sn63Pb37 finish. The choke operates efficiently within a temperature range of -55°C to +130°C and is rated at moisture sensitivity level (MSL) 1, ensuring reliability in various environments. The product is packaged in bulk, weighing 7 grams, with dimensions of 16.76 × 16.76 × 10.67 mm.
| Weight | 7 g |
|---|---|
| Dimensions | 16.76 × 16.76 × 10.67 mm |
| Series | ATHM |
| Mounting Type | SMT |
| Inductance (µH) | 3.9 |
| DCR (Ω) | 0.006 |
| SRF (MHz) | 35 |
| Current Rating (A DC) | 9.5 |
| INC I L (Δ10% mA DC) | 8500 |
| INC I L (Δ20% mA DC) | 12000 |
| Tolerance | ±15% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Operating Temperature | -55°C to +130°C |
| MSL | 1 |
| Packaging | Bulk |
Horizontal Mount Standoff Toroidal Choke
