Gowanda’s 059AT1002HCLF is a high-quality Horizontal Encapsulated Toroidal Power Choke, part of the ATHC series, designed for surface mount technology (SMT) applications. It features an inductance of 10 µH with a low direct current resistance (DCR) of 0.008 Ω and a self-resonant frequency (SRF) of 10 MHz. This component supports a current rating of 14.5 A DC and can handle incremental current levels of 15000 mA DC with a 10% change and 20000 mA DC with a 20% change. It offers a tolerance of ±10% and is compliant with RoHS standards, featuring a Sn/Cu termination finish. The choke operates efficiently across a wide temperature range from -55°C to +130°C and is classified with a moisture sensitivity level (MSL) of 1, ensuring reliability in various environmental conditions. It is available in bulk packaging, weighing 33 grams with dimensions of 31.75 × 31.75 × 16.51 mm.
| Weight | 33 g |
|---|---|
| Dimensions | 31.75 × 31.75 × 16.51 mm |
| Series | ATHC |
| Mounting Type | SMT |
| Inductance (µH) | 10 |
| DCR (Ω) | 0.008 |
| SRF (MHz) | 10 |
| Current Rating (A DC) | 14.5 |
| INC I L (Δ10% mA DC) | 15000 |
| INC I L (Δ20% mA DC) | 20000 |
| Tolerance | ±10% |
| Termination Type | RoHS |
| Termination Finish | Sn/Cu |
| Operating Temperature | -55°C to +130°C |
| MSL | 1 |
| Packaging | Bulk |
Horizontal Encapsulated Toroidal Power Choke
