059AT1003VCLF

Gowanda’s 059AT1003VCLF is a high-quality Vertical Mount Encapsulated Toroidal Choke, designed for reliability and efficiency in electronic applications. Weighing 28 grams and measuring 30.73 × 17.4 × 29.85 mm, this component is part of the ATVC series and features a Through-Hole Technology (THT) mounting type. It is suitable for COTS+ application grades, offering an inductance of 100 µH with a direct current resistance (DCR) of 0.044 Ω and a self-resonant frequency (SRF) of 2 MHz. The choke supports a current rating of 4.9 A DC, with incremental current limits of 6500 mA DC for a 10% change and 8200 mA DC for a 20% change. It has a tolerance of ±10% and is RoHS compliant with a Sn/Cu termination finish. The component operates effectively within a temperature range of -55°C to +130°C and has a moisture sensitivity level (MSL) of 1, making it ideal for bulk packaging.
