Gowanda’s 10MG390JLF is a high-quality molded non-magnetic inductor designed for medical applications. Weighing just 0.3 grams, it features compact dimensions of 6.35 × 2.413 × 2.413 mm and is part of the 10MG series. This through-hole technology (THT) component offers an inductance of 0.39 µH with a Q minimum of 30, tested at a frequency of 25 MHz. It has a direct current resistance (DCR) of 0.3 ohms and a self-resonant frequency (SRF) of 365 MHz, supporting a current rating of 0.7 A DC with a tolerance of ±5%. The inductor is RoHS compliant with a SnCu termination finish and operates effectively within a temperature range of -55°C to +125°C. It is packaged in tape and reel (T&R) format and has a moisture sensitivity level (MSL) of 1, ensuring reliability and ease of use in various medical-grade applications.
| Weight | 0.3 g |
|---|---|
| Dimensions | 6.35 × 2.413 × 2.413 mm |
| Series | 10MG |
| Mounting Type | THT |
| Application Grade | Medical |
| Inductance (µH) | 0.39 |
| Q MIN | 30 |
| Test Freq (MHz) | 25 |
| DCR (Ω) | 0.3 |
| SRF (MHz) | 365 |
| Current Rating (A DC) | 0.7 |
| Tolerance | ±5% |
| Termination Type | RoHS |
| Termination Finish | SnCu |
| Core | Non-Magnetic |
| Shielded | No |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | T&R |
Molded Non-Magnetic Inductor
