15MG390JLF

Gowanda’s 15MG390JLF is a molded non-magnetic inductor designed for medical applications, featuring a compact size with dimensions of 9.525 × 3.962 × 3.962 mm and a weight of 0.65 g. This inductor belongs to the 15MG series and is mounted using through-hole technology (THT). It offers an inductance of 0.39 µH with a Q minimum of 45 at a test frequency of 25 MHz. The device has a direct current resistance (DCR) of 0.1 Ω and a self-resonant frequency (SRF) of 325 MHz, supporting a current rating of 1.349 A DC with a tolerance of ±5%. The inductor is RoHS compliant with a SnCu termination finish and operates within a temperature range of -55°C to +125°C. It is packaged in tape and reel (T&R) format, has a moisture sensitivity level (MSL) of 1, and is fungal inert.

Weight 0.65 g
Dimensions 9.525 × 3.962 × 3.962 mm
Series

15MG

Mounting Type

THT

Application Grade

Medical

Inductance (µH)

0.39

Q MIN

45

Test Freq (MHz)

25

DCR (Ω)

0.1

SRF (MHz)

325

Current Rating (A DC)

1.349

Tolerance

±5%

Termination Type

RoHS

Termination Finish

SnCu

Core

Non-Magnetic

Shielded

No

Operating Temperature

-55°C to +125°C

MSL

1

Packaging

T&R

Fungal Inert

Yes

Molded Non-Magnetic Inductor
