1B104

Gowanda’s 1B104 Wirewound High Current Power Choke is a robust component designed for demanding applications. Weighing 8.5 grams and measuring 29.85 × 14.61 × 14.61 mm, this Series B choke is mounted using THT and is suitable for COTS+ grade applications. It offers an inductance of 1000 µH with a DCR of 0.6 Ω and a current rating of 1 A DC, ensuring reliable performance. The component features a tolerance of ±10% and uses Pb termination with a Sn63Pb37 finish. It operates efficiently across a temperature range of -55°C to +130°C, has an MSL of 1, and is available in bulk packaging.

Weight 8.5 g
Dimensions 29.85 × 14.61 × 14.61 mm
Series

B

Mounting Type

THT

Application Grade

COTS+

Inductance (µH)

1000

DCR (Ω)

0.6

Current Rating (A DC)

1

Tolerance

±10%

Termination Type

Pb

Termination Finish

Sn63Pb37

Operating Temperature

-55°C to +130°C

MSL

1

Packaging

Bulk

Wirewound High Current Power Choke
