Gowanda’s 3B752 is a wirewound high current power choke designed for demanding applications, featuring a compact form factor with dimensions of 21.59 × 12.7 × 12.7 mm and a weight of 10 grams. Part of Series B, this component is tailored for COTS+ application grade, ensuring reliability and performance. It offers an inductance of 75 µH with a DCR of 0.12 Ω and a current rating of 3 A DC, maintaining a tolerance of ±10%. The choke is mounted using through-hole technology (THT) and features Pb termination with a Sn63Pb37 finish. It operates efficiently across a wide temperature range from -55°C to +130°C, with a moisture sensitivity level (MSL) of 1, and is available in bulk packaging.
| Weight | 10 g |
|---|---|
| Dimensions | 21.59 × 12.7 × 12.7 mm |
| Series | B |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 75 |
| DCR (Ω) | 0.12 |
| Current Rating (A DC) | 3 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Operating Temperature | -55°C to +130°C |
| MSL | 1 |
| Packaging | Bulk |
Wirewound High Current Power Choke
