894AT2502HCLF

Gowanda’s 894AT2502HCLF is a high-quality Horizontal Encapsulated Toroidal Power Choke, part of the ATHC series, designed for surface mount technology (SMT) applications. This component features an inductance of 25 µH with a direct current resistance (DCR) of 0.012 Ω and a self-resonant frequency (SRF) of 5 MHz. It supports a current rating of 12.8 A DC and can handle incremental current changes of 13,500 mA DC at a 10% inductance drop and 20,000 mA DC at a 20% drop. With a tolerance of ±10%, the choke is RoHS compliant, featuring Sn/Cu termination finish, and operates efficiently within a temperature range of -55°C to +130°C. It is packaged in bulk and has a moisture sensitivity level (MSL) of 1, ensuring reliability and durability in various electronic applications.
