Gowanda’s 894T2005 is a self-leaded high inductance toroidal inductor, part of the T-Large series, designed for high-frequency applications. It features a compact design with dimensions of 35.56 × 35.56 × 17.78 mm and weighs 54 grams. This through-hole technology (THT) component is suitable for COTS+ application grades, offering an inductance of 20000 µH with a tolerance of ±2%. It has a direct current resistance (DCR) of 4.5 Ω and a current rating of 0.324 A DC, with a self-resonant frequency (SRF) of 0.12 MHz. The inductor operates efficiently within a temperature range of -40°C to +105°C and has a moisture sensitivity level (MSL) of 1. It features a Pb termination type with a Sn63Pb37 finish and is available in bulk packaging.
| Weight | 54 g |
|---|---|
| Dimensions | 35.56 × 35.56 × 17.78 mm |
| Series | T-Large |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 20000 |
| DCR (Ω) | 4.5 |
| Current Rating (A DC) | 0.324 |
| SRF (MHz) | 0.12 |
| Frequency | High |
| Tolerance | ±2% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Operating Temperature | -40°C to +105°C |
| MSL | 1 |
| Packaging | Bulk |
Self-Leaded High Inductance Toroidal Inductor
