CMF4-5004VMLF

Gowanda’s CMF4-5004VMLF is a vertical mount common mode choke designed for high reliability and performance in electronic applications. Weighing 13.5 grams and measuring 25.4 × 15.24 × 25.4 mm, this component is part of the CMF4VM series and features through-hole technology (THT) for mounting. It is suitable for COTS+ grade applications, offering an inductance of 5000 µH and a direct current resistance (DCR) of 0.15 Ω. The choke supports a current rating of 2 A DC and has an interwinding capacitance of 19 pF, with a leakage inductance of 50 µH. It can withstand a dielectric withstanding voltage (DWV) of 1250 and operates within a temperature range of -55°C to +125°C. The component is RoHS compliant with a Sn100 termination finish, and it is packaged in bulk. It is not shielded and has a moisture sensitivity level (MSL) of 1, though it is not fungal inert.
