Gowanda’s CMF5-3304HLF is a high-quality horizontal mount common mode choke designed for reliable performance in various applications. With a weight of 39.98 grams and dimensions of 38.1 × 38.1 × 17.15 mm, this component is part of the CMF5H series and features through-hole technology (THT) for mounting. It is classified under the COTS+ application grade, offering an inductance of 3300 µH and a direct current resistance (DCR) of 0.035 Ω. The choke supports a current rating of 6 A DC and has an interwinding capacitance of 19 pF, with a leakage inductance of 27 µH. It can withstand a dielectric withstanding voltage (DWV) of 1250 and has a tolerance of ±25%. The component is RoHS compliant with a Sn100 termination finish, operates within a temperature range of -55°C to +125°C, and has a moisture sensitivity level (MSL) of 1. It is packaged in bulk and is not shielded or fungal inert.
| Weight | 39.98 g |
|---|---|
| Dimensions | 38.1 × 38.1 × 17.15 mm |
| Series | CMF5H |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 3300 |
| DCR (Ω) | 0.035 |
| Current Rating (A DC) | 6 |
| Interwinding Capacitance (pF) | 19 |
| Leakage Inductance (µH) | 27 |
| DWV | 1250 |
| Tolerance | ±25% |
| Termination Type | RoHS |
| Termination Finish | Sn100 |
| Shielded | No |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | Bulk |
| Fungal Inert | No |
Horizontal Mount Common Mode Choke
