Gowanda’s CMF5-5004VM is a high-quality vertical mount common mode choke designed for reliable performance in demanding applications. Weighing 36.73 grams and measuring 36.8 × 35.6 × 20.32 mm, this component is part of the CMF5VM series and features through-hole technology (THT) for secure mounting. It is suitable for COTS+ application grades, offering an inductance of 5000 µH and a direct current resistance (DCR) of 0.06 Ω. The choke supports a current rating of 4.6 A DC, with an interwinding capacitance of 20 pF and a leakage inductance of 42 µH. It has a dielectric withstanding voltage (DWV) of 1250 and a tolerance of ±25%. The termination type is lead-based with a Sn63Pb37 finish, and it operates effectively in temperatures ranging from -55°C to +125°C. With a moisture sensitivity level (MSL) of 1, it is packaged in bulk and is not fungal inert.
| Weight | 36.73 g |
|---|---|
| Dimensions | 36.8 × 35.6 × 20.32 mm |
| Series | CMF5VM |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 5000 |
| DCR (Ω) | 0.06 |
| Current Rating (A DC) | 4.6 |
| Interwinding Capacitance (pF) | 20 |
| Leakage Inductance (µH) | 42 |
| DWV | 1250 |
| Tolerance | ±25% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Shielded | No |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | Bulk |
| Fungal Inert | No |
Vertical Mount Common Mode Choke
