Gowanda’s SML32-222KLF is a high-quality molded unshielded surface mount inductor, designed for reliable performance in various electronic applications. Weighing just 0.05 grams, this compact component measures 2.98 × 2.29 × 2.18 mm and belongs to the SML32 series. It features a surface mount technology (SMT) mounting type and is classified under the COTS+ application grade. With an inductance of 22 µH, a DCR of 3.7 Ω, and a current rating of 0.224 A DC, it operates efficiently within a frequency range, boasting a self-resonant frequency (SRF) of 25 MHz and a test frequency of 2.52 MHz. The inductor offers a minimum Q factor of 30 and a tolerance of ±10%. It is RoHS compliant with Sn100 termination finish and a ferrite core, ensuring durability and performance across a wide operating temperature range of -55°C to +125°C. The product is packaged in tape and reel (T&R) format, is fungal inert, and has a moisture sensitivity level (MSL) of 1, making it suitable for various demanding environments.
| Weight | 0.05 g |
|---|---|
| Dimensions | 2.98 × 2.29 × 2.18 mm |
| Series | SML32 |
| Mounting Type | SMT |
| Application Grade | COTS+ |
| Inductance (µH) | 22 |
| DCR (Ω) | 3.7 |
| Current Rating (A DC) | 0.224 |
| SRF (MHz) | 25 |
| Test Freq (MHz) | 2.52 |
| Q MIN | 30 |
| Tolerance | ±10% |
| Termination Type | RoHS |
| Termination Finish | Sn100 |
| Core | Ferrite |
| Shielded | No |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | T&R |
| Fungal Inert | Yes |
Molded Unshielded Surface Mount Inductor
