SML32S-123MLF

Gowanda’s SML32S-123MLF is a molded shielded surface mount inductor designed for high reliability and performance in electronic applications. Weighing just 0.05 grams, this compact component measures 2.98 × 2.29 × 2.18 mm and is part of the SML32S series. It features a surface mount technology (SMT) mounting type and is suitable for COTS+ application grades. With an inductance of 120 µH, a direct current resistance (DCR) of 11 Ω, and a current rating of 0.137 A DC, it operates effectively within a frequency range of 0.79 MHz and a self-resonant frequency (SRF) of 5 MHz. The inductor is RoHS compliant with a Sn100 termination finish and is constructed with a ferrite core, ensuring it is shielded and operates reliably in temperatures ranging from -55°C to +125°C. It has a moisture sensitivity level (MSL) of 1 and is packaged in tape and reel (T&R) format, making it ideal for automated assembly processes. Additionally, it is fungal inert, enhancing its durability in various environments.

Weight 0.05 g
Dimensions 2.98 × 2.29 × 2.18 mm
Series

SML32S

Mounting Type

SMT

Application Grade

COTS+

Inductance (µH)

120

DCR (Ω)

11

Current Rating (A DC)

0.137

SRF (MHz)

5

Test Freq (MHz)

0.79

Tolerance

±20%

Termination Type

RoHS

Termination Finish

Sn100

Core

Ferrite

Shielded

Yes

Operating Temperature

-55°C to +125°C

MSL

1

Packaging

T&R

Fungal Inert

Yes

Molded Shielded Surface Mount Inductor
