Gowanda’s 894KM1004RM is a horizontally mounted, ruggedized toroidal inductor designed for high reliability in demanding applications. Part of the KMRM series, this component features a through-hole technology (THT) mounting type and is classified under the COTS+ application grade, ensuring it meets commercial off-the-shelf standards with enhanced performance. It offers an inductance of 1000 µH with a tolerance of ±10%, a direct current resistance (DCR) of 0.235 Ω, and a self-resonant frequency (SRF) of 0.4 MHz. The inductor supports a current rating of 2.4 A DC, with incremental current levels of 1000 mA DC for a 10% change and 1800 mA DC for a 20% change. It is built to operate in a wide temperature range from -55°C to +130°C and has a moisture sensitivity level (MSL) of 1, indicating high reliability in various environments. The termination type is lead-based (Pb) with a finish of Sn63Pb37, and it is available in bulk packaging. With dimensions of 34 × 34 × 20.32 mm and a weight of 57 g, this inductor is ideal for applications requiring robust performance and durability.
| Weight | 57 g |
|---|---|
| Dimensions | 34 × 34 × 20.32 mm |
| Series | KMRM |
| Mounting Type | THT |
| Application Grade | COTS+ |
| Inductance (µH) | 1000 |
| DCR (Ω) | 0.235 |
| SRF (MHz) | 0.4 |
| Current Rating (A DC) | 2.4 |
| INC I L (Δ10% mA DC) | 1000 |
| INC I L (Δ20% mA DC) | 1800 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Sn63Pb37 |
| Operating Temperature | -55°C to +130°C |
| MSL | 1 |
| Packaging | Bulk |
Horizontal Mount Ruggedized Toroidal Inductor
