Gowanda’s GP3042-101MLF is a high-quality shielded power choke designed for reliable performance in electronic applications. Weighing 0.85 grams and measuring 5.8 × 5.8 × 2.29 mm, this component is part of the GP3042 series and features surface mount technology (SMT) for easy integration. It is suitable for COTS+ application grades, offering an inductance of 100 µH with a direct current resistance (DCR) of 0.7 Ω and a current rating of 0.12 A DC. The choke operates effectively at a test frequency of 1 MHz and has a self-resonant frequency (SRF) of 11 MHz, with a tolerance of ±20%. It is RoHS compliant with Sn100 termination finish and features a ferrite core for enhanced performance. The component is shielded, ensuring minimal electromagnetic interference, and operates within a temperature range of -55°C to +125°C. It has a moisture sensitivity level (MSL) of 1 and is available in tape and reel (T&R) packaging for efficient handling and assembly.
| Weight | 0.85 g |
|---|---|
| Dimensions | 5.8 × 5.8 × 2.29 mm |
| Series | GP3042 |
| Mounting Type | SMT |
| Application Grade | COTS+ |
| Inductance (µH) | 100 |
| DCR (Ω) | 0.7 |
| Current Rating (A DC) | 0.12 |
| Test Freq (MHz) | 1 |
| SRF (MHz) | 11 |
| Tolerance | ±20% |
| Termination Type | RoHS |
| Termination Finish | Sn100 |
| Core | Ferrite |
| Shielded | Yes |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | T&R |
Shielded Power Choke
