Gowanda’s CMF3-3003SMLF is a high-quality common mode transformer choke designed for demanding applications. With a weight of 9.73 grams and compact dimensions of 26.87 × 26.87 × 10.74 mm, it is part of the CMF3SM series and features surface mount technology (SMT) for easy integration. This component is suitable for COTS+ application grade, offering an inductance of 300 µH and a direct current resistance (DCR) of 0.018 Ω. It supports a current rating of 6.3 A DC and has a leakage inductance of 3 µH. The device is shielded, RoHS compliant, and features a Sn100 termination finish. It operates reliably across a wide temperature range from -55°C to +125°C, with a dielectric withstanding voltage (DWV) of 1250. The CMF3-3003SMLF is packaged in tape and reel (T&R) format, has a moisture sensitivity level (MSL) of 1, and is fungal inert, ensuring durability and performance in various environments.
| Weight | 9.73 g |
|---|---|
| Dimensions | 26.87 × 26.87 × 10.74 mm |
| Series | CMF3SM |
| Mounting Type | SMT |
| Application Grade | COTS+ |
| Inductance (µH) | 300 |
| DCR (Ω) | 0.018 |
| Current Rating (A DC) | 6.3 |
| Leakage Inductance (µH) | 3 |
| DWV | 1250 |
| Tolerance | ±30% |
| Termination Type | RoHS |
| Termination Finish | Sn100 |
| Shielded | Yes |
| Operating Temperature | -55°C to +125°C |
| MSL | 1 |
| Packaging | T&R |
| Fungal Inert | Yes |
Common Mode Transformer Choke
